Automatic 10L 20L 30L Plastic Bucket Extrusion Blow Molding Machine

The Automatic plastic HDPE open head 30L barrel blow molding machine is used to make abs car hollow products , A wide variety of materials can be used for the machine, which are suitable for producing 10-30L PE bottle. Extrusion system using a hard gear reducer and inverter. The die head system adopts central-inco

Featured Products

The Automatic plastic HDPE open head 30L barrel blow molding machine is used to make abs car hollow products , A wide variety of materials can be used for the machine, which are suitable for producing 10-30L PE bottle. Extrusion system using a hard gear reducer and inverter. The die head system adopts central-incoming extrusion die made of special steel, imported hydraulic valve and seal parts with proportional control valve. The control system consists of PLC and Human-machine interface imported from Japan, an automatic temperature control module and imported electrical parts.

Blow molding machine parameter
ItemCode itemParameterNote
Extruder
(Main extruder )
Max capacity30L
Main screwØ100mmHigh efficiency mixing
Screw L/D25-30
Screw material 38CrMoALA
Max.Extruder consumption110KG/hr
Twisting transition methodElectrical machinery,Gear box,AC motorHard gear surface decelerator with AC regulator
Driving motor30KW
Screw rotate speed60-90r/min
Ahead/back adjustingYes
Up/ down adjustingYes
Temperature control zone5
Heating power22kw
Cooling for blower5
Cooling functionYesCooling water
Clamping unit
(Mold openiing/closing unit)
Structure With three bar timing clamping structure in high speed and high force,to achieve quality products
Clamping directionsLinear guideFor high precise location for longer service life
Platen dimension750*850mm(W*H)
Max.mold dimension700*650mm(W*H)
Platen distance450-1000mmMin.-Max.
Clamping force230KN
Mold thickness stroke610-750mm
Fixing pattern of moldMold press platen
Mold open/close stroke controlInducing Switch +movingDiscriminate mold opening/closing end,mold opening/closing slow speed
Light Electric Safety protect Taiwan
Die headFormAccumulatorFirst in ,First out
Material 38CrMoALA,inner mirror treatment
Accumulator volume3.5 L
Output of injecting2.6 kgHDPE,5502
Max die-pin diameter 350 mm
Heating Method Stainless steel heating ring,precision +1%
Temperature control zone4
Blow-airYes
Adjusting of parison thicknessYesMOOG OR GEFRAN
Adjusting method of thicknessInner mold adjusting+5mm

Blow molding machine photo
Fully Automatic 10 Liter 20 Liter 30 Liter Plastic Barrel Extrusion Blow Moulding Machine
Fully Automatic 10 Liter 20 Liter 30 Liter Plastic Barrel Extrusion Blow Moulding Machine
Fully Automatic 10 Liter 20 Liter 30 Liter Plastic Barrel Extrusion Blow Moulding Machine
Fully Automatic 10 Liter 20 Liter 30 Liter Plastic Barrel Extrusion Blow Moulding Machine
Fully Automatic 10 Liter 20 Liter 30 Liter Plastic Barrel Extrusion Blow Moulding Machine
Fully Automatic 10 Liter 20 Liter 30 Liter Plastic Barrel Extrusion Blow Moulding Machine
Fully Automatic 10 Liter 20 Liter 30 Liter Plastic Barrel Extrusion Blow Moulding Machine
Fully Automatic 10 Liter 20 Liter 30 Liter Plastic Barrel Extrusion Blow Moulding Machine


Welcome you contact us for more machine details.
